CARBON FIBER FOOT BASE
The heel spring and toe spring were meticulously crafted utilizing maximum stress predictions to increase strength and prevent failure. The design allows the carbon fiber composite to be pushed to the limit, providing greater flexibility and dynamic response.
DYNAMIC GAIT CYCLE
9 degrees of dampened plantarflexion give comfort while 3 degrees of dorsiflexion provide a smooth, balanced rollover that engages the dynamic carbon composite foot base.
REVOLUTIONARY CURVED HYDRAULIC ANKLE
The College Park OdysseyK3 foot provides fluid control and incredible ground contact. The patented curved hydraulic cylinder allows for one pivot point, resulting in a smoother sweep, longer life and the lowest profile hydraulic foot to date.
- Specs & Downloads
*26cm, with Enviroshell and CPI sock.
** The listing of codes with these products should not be construed as a guarantee for coverage or payment. Ultimate responsibility for the coding of services/products rests with the individual practitioner.
Impact Level Low - Moderate Mounting Endo (IP) Weight Limit 275 lbs (125 kg) Size Range 21-30 cm Clearance 3.0” (7.5-7.7 cm) Weight* 750 g Warranty 3 years
Cosmetic OptionsColor OptionsCaucasianTanBrownJet BlackShell Type: Sandal ToeIncludes: Foot, foot shell, CPI sock
